ALLESTIMENTO AUTO
BULLONERIA NAS
Bulloneria NAS Serie 1303/6603.
Hanno resistenza alla trazione minima di 160.000 psi e resistenza minima al taglio di 95.000 psi.
La lunghezza della filettatura è adeguata per ogni diametro (la serie 1103/6203 ha un filetto più corto).
Utilizzato in applicazioni dove è necessaria un’ elevata qualità e resistenza.
Codice Passo Grip Codice Passo Passo Codice Passo Passo
1303-01 10-32 UNF 1,59 mm 1304-13 1/4” x 28 UNF 20,64 mm 1305-11 5/16” x 24 UNF 17,46 mm
1303-02 10-32 UNF 3,18 mm 1304-14 1/4” x 28 UNF 22,23 mm 1305-12 5/16” x 24 UNF 19,05 mm
1303-03 10-32 UNF 4,76 mm 1304-15 1/4” x 28 UNF 23,81 mm 1305-13 5/16” x 24 UNF 20,64 mm
1303-04 10-32 UNF 6,35 mm 1304-16 1/4” x 28 UNF 25,40 mm 1305-14 5/16” x 24 UNF 22,23 mm
1303-05 10-32 UNF 7,94 mm 1304-17 1/4” x 28 UNF 26,99 mm 1305-15 5/16” x 24 UNF 23,81 mm
1303-06 10-32 UNF 9,53 mm 1304-18 1/4” x 28 UNF 28,58 mm 1305-16 5/16” x 24 UNF 25,40 mm
1303-07 10-32 UNF 11,11 mm 1304-19 1/4” x 28 UNF 30,16 mm 1305-17 5/16” x 24 UNF 26,99 mm
1303-08 10-32 UNF 12,70 mm 1304-20 1/4” x 28 UNF 31,75 mm 1305-18 5/16” x 24 UNF 28,58 mm
1303-09 10-32 UNF 14,29 mm 1304-21 1/4” x 28 UNF 33,34 mm 1305-19 5/16” x 24 UNF 30,16 mm
1303-10 10-32 UNF 15,88 mm 1304-22 1/4” x 28 UNF 34,93 mm 1305-20 5/16” x 24 UNF 31,75 mm
1303-11 10-32 UNF 17,46 mm 1304-23 1/4” x 28 UNF 36,51 mm 1305-21 5/16” x 24 UNF 33,34 mm
1303-12 10-32 UNF 19,05 mm 1304-24 1/4” x 28 UNF 38,10 mm 1305-22 5/16” x 24 UNF 34,93 mm
RACCORDERIA
E TUBAZIONI
1303-13 10-32 UNF 20,64 mm 1304-25 1/4” x 28 UNF 39,69 mm 1305-23 5/16” x 24 UNF 36,51 mm
1303-14 10-32 UNF 22,23 mm 1304-26 1/4” x 28 UNF 41,28 mm 1305-24 5/16” x 24 UNF 38,10 mm
1303-15 10-32 UNF 23,81 mm 1304-27 1/4” x 28 UNF 42,86 mm 1305-25 5/16” x 24 UNF 39,69 mm
SISTEMI
1303-16 10-32 UNF 25,40 mm 1304-28 1/4” x 28 UNF 44,45 mm 1305-26 5/16” x 24 UNF 41,28 mm
CARBURANTE
1303-17 10-32 UNF 26,99 mm 1304-29 1/4” x 28 UNF 46,04 mm 1305-27 5/16” x 24 UNF 42,86 mm
1303-18 10-32 UNF 28,58 mm 1304-30 1/4” x 28 UNF 47,63 mm 1305-28 5/16” x 24 UNF 44,45 mm
1303-19 10-32 UNF 30,16 mm 1304-31 1/4” x 28 UNF 49,21 mm 1305-29 5/16” x 24 UNF 46,04 mm
1303-20 10-32 UNF 31,75 mm 1304-32 1/4” x 28 UNF 50,80 mm 1305-30 5/16” x 24 UNF 47,63 mm
SISTEMI DI RAF-
FREDDAMENTO
1304-01 1/4” x 28 UNF 1,59 mm 1304-34 1/4” x 28 UNF 53,98 mm 1305-31 5/16” x 24 UNF 49,21 mm
1304-02 1/4” x 28 UNF 3,18 mm 1304-60 1/4” x 28 UNF 95,25 mm 1305-32 5/16” x 24 UNF 50,80 mm
1304-03 1/4” x 28 UNF 4,76 mm 1305-01 5/16” x 24 UNF 1,59 mm 1305-34 5/16” x 24 UNF 53,98 mm QUALITÄT UND DYNAMIK IN PERFEKTION PERFECT QUALITY AND DYNAMIC
1304-04 1/4” x 28 UNF 6,35 mm 1305-02 5/16” x 24 UNF 3,18 mm 1305-38 5/16” x 24 UNF 60,33 mm
TRASMISSIONE
1304-05 1/4” x 28 UNF 7,94 mm 1305-03 5/16” x 24 UNF 4,76 mm 1305-40 5/16” x 24 UNF 63,50 mm
MOTORE-CAMBIO
1304-06 1/4” x 28 UNF 9,53 mm 1305-04 5/16” x 24 UNF 6,35 mm 1305-42 5/16” x 24 UNF 66,68 mm
1304-07 1/4” x 28 UNF 11,11 mm 1305-05 5/16” x 24 UNF 7,94 mm 1305-44 5/16” x 24 UNF 69,85 mm
1304-08 1/4” x 28 UNF 12,70 mm 1305-06 5/16” x 24 UNF 9,53 mm 1305-56 5/16” x 24 UNF 88,90 mm
IMPIANTI
FRENANTI
1304-09 1/4” x 28 UNF 14,29 mm 1305-07 5/16” x 24 UNF 11,11 mm 1306-01 3/8” x 24 UNF 1,59 mm
1304-10 1/4” x 28 UNF 15,88 mm 1305-08 5/16” x 24 UNF 12,70 mm 1306-02 3/8” x 24 UNF 3,18 mm
1304-11 1/4” x 28 UNF 17,46 mm 1305-09 5/16” x 24 UNF 14,29 mm 1306-03 3/8” x 24 UNF 4,76 mm
1304-12 1/4” x 28 UNF 19,05 mm 1305-10 5/16” x 24 UNF 15,88 mm 1306-04 3/8” x 24 UNF 6,35 mm
AUTO
ALLESTIMENTO
1306-05 3/8” x 24 UNF 7,94 mm 1306-29 3/8” x 24 UNF 46,04 mm 1307-14 7/16” x 20 UNF 22,23 mm
1306-06 3/8” x 24 UNF 9,53 mm 1306-30 3/8” x 24 UNF 47,63 mm 1307-15 7/16” x 20 UNF 23,81 mm
1306-07 3/8” x 24 UNF 11,11 mm 1306-31 3/8” x 24 UNF 49,21 mm 1307-16 7/16” x 20 UNF 25,40 mm
1306-08 3/8” x 24 UNF 12,70 mm 1306-32 3/8” x 24 UNF 50,80 mm 1307-17 7/16” x 20 UNF 26,99 mm
BULLONERIA
CERCHI E GOMME
1306-09 3/8” x 24 UNF 14,29 mm 1306-34 3/8” x 24 UNF 53,98 mm 1307-18 7/16” x 20 UNF 28,58 mm
1306-10 3/8” x 24 UNF 15,88 mm 1306-36 3/8” x 24 UNF 57,15 mm 1307-19 7/16” x 20 UNF 30,16 mm
1306-11 3/8” x 24 UNF 17,46 mm 1306-40 3/8” x 24 UNF 60,33 mm 1307-20 7/16” x 20 UNF 31,75 mm
1306-12 3/8” x 24 UNF 19,05 mm 1306-42 3/8” x 24 UNF 63,50 mm 1307-21 7/16” x 20 UNF 33,34 mm
ELETTRICI
COMPONENTI
1306-13 3/8” x 24 UNF 20,64 mm 1306-44 3/8” x 24 UNF 66,68 mm 1307-22 7/16” x 20 UNF 34,93 mm
1306-14 3/8” x 24 UNF 22,23 mm 1306-54 3/8” x 24 UNF 69,85 mm 1307-23 7/16” x 20 UNF 36,51 mm
1306-15 3/8” x 24 UNF 23,81 mm 1306-56 3/8” x 24 UNF 88,90 mm 1307-24 7/16” x 20 UNF 38,10 mm
1306-16 3/8” x 24 UNF 25,40 mm 1307-01 7/16” x 20 UNF 1,59 mm 1307-25 7/16” x 20 UNF 39,69 mm
1306-17 3/8” x 24 UNF 26,99 mm 1307-02 7/16” x 20 UNF 3,18 mm 1307-26 7/16” x 20 UNF 41,28 mm
ABBIGLIAMENTO
1306-18 3/8” x 24 UNF 28,58 mm 1307-03 7/16” x 20 UNF 4,76 mm 1307-27 7/16” x 20 UNF 42,86 mm
1306-19 3/8” x 24 UNF 30,16 mm 1307-04 7/16” x 20 UNF 6,35 mm 1307-28 7/16” x 20 UNF 44,45 mm
1306-20 3/8” x 24 UNF 31,75 mm 1307-05 7/16” x 20 UNF 7,94 mm 1307-29 7/16” x 20 UNF 46,04 mm
TECNICHE
ATTREZZATURE
1306-21 3/8” x 24 UNF 33,34 mm 1307-06 7/16” x 20 UNF 9,53 mm 1307-30 7/16” x 20 UNF 47,63 mm
1306-22 3/8” x 24 UNF 34,93 mm 1307-07 7/16” x 20 UNF 11,11 mm 1307-31 7/16” x 20 UNF 49,21 mm
1306-23 3/8” x 24 UNF 36,51 mm 1307-08 7/16” x 20 UNF 12,70 mm 1307-32 7/16” x 20 UNF 50,80 mm
1306-24 3/8” x 24 UNF 38,10 mm 1307-09 7/16” x 20 UNF 14,29 mm 1307-34 7/16” x 20 UNF 53,98 mm
DISTANZIALI
E BULLONERIA
1306-25 3/8” x 24 UNF 39,69 mm 1307-10 7/16” x 20 UNF 15,88 mm 1307-38 7/16” x 20 UNF 60,33 mm
1306-26 3/8” x 24 UNF 41,28 mm 1307-11 7/16” x 20 UNF 17,46 mm 1307-40 7/16” x 20 UNF 63,50 mm
1306-27 3/8” x 24 UNF 42,86 mm 1307-12 7/16” x 20 UNF 19,05 mm
1306-28 3/8” x 24 UNF 44,45 mm 1307-13 7/16” x 20 UNF 20,64 mm
VINTAGE
E TUNING
WWW.MAXICARRACING.COM *Componenti racing solo per uso competizione
